IG-CO2 SERIES INCUBATOR:
The IG-CO₂ Series Incubators are expertly crafted to create a controlled environment that mimics natural conditions for growing cells and tissues. Featuring advanced 6-side direct heat technology, they provide consistent and uniform heating throughout the chamber. Coupled with precise temperature control and CO2 level regulation, these incubators ensure a stable and ideal atmosphere for cell culture.
KEY FEATURES OF THE IG-CO2 SERIES INCUBATOR:
- 6-Side Direct Heat Chamber: Ensures uniform temperature distribution with six- sided heating. The temperature field stabilizes at ±0.1°C, creating an ideal environment for cell and tissue cultivation.
- Polished Stainless Steel Interior: The one-piece, polished stainless-steel chamber is designed for easy cleaning. Rounded corners and removable stainless-steel shelves allow for quick maintenance without tools.
- Detachable Humidity Pan:A 304 stainless steel water pan with a 4-liter capacity maintains a high-humidity environment.
- Versatile Sterilization Options: Choose between UV sterilization or high heat sterilization at 140°C or 180°C, offering flexible and powerful sterilization options for hygiene and safety.
- ISO Class 5 HEPA-Filtered Airflow System: Integrated HEPA filtration achieves ISO Class 5 air quality within 5 minutes of closing the door, continuously protecting against airborne contaminants.
- Infrared (IR) CO2 Sensor: Provides accurate CO2 concentration monitoring, minimizing errors from humidity or temperature fluctuations, especially useful for frequent door openings.
- Active Airflow Technology: Fan-assisted airflow ensures rapid recovery of temperature and gas conditions, maintaining a consistent environment throughout the chamber.
- 5-Inch LCD Touchscreen: A user-friendly touchscreen offers intuitive controls for settings, with audible/visual alarms, historical data display, and USB data export options.
- Steel Shelves: Includes a minimum of three (3) steel shelves for efficient storage and organization.
- Condensation Prevention: Heating elements around the front door and frame eliminate condensation buildup on the chamber and glass door.
- Energy Efficiency: Optimized for lower gas and heat consumption, with faster recovery times and efficient management for various sample types.
- Overheating Protection: A safety feature automatically cuts off heating if the temperature exceeds the set limit or if the control system malfunctions
- Double-Walled Modular Design: Features 3-inch thick glass wool blanket insulation for superior temperature retention and energy efficiency.
SPECIFICATIONS:
| Parameter | CO2 Incubator (IG-CO2 Series) | Tri-Gas Incubator (IG-TRIG Series) |
|---|---|---|
| Model Variants | IG-CO280 / IG-CO2180 (UV / 140°C / 180°C) | IG-TRIG80 / IG-TRIG180 (UV / 140°C / 180°C) |
| Volume | 80L / 180L | 80L / 180L |
| Controller | Microprocessor-based (CO2 & Temp control) | Microprocessor-based (CO2, O2, N2 & Temp control) |
| Display | LCD Touchscreen | LCD Touchscreen |
| Temperature Range | Ambient +5°C to 60°C | Ambient +5°C to 60°C |
| Temperature Stability | ±0.1°C | ±0.1°C |
| Temperature Accuracy | ±0.3°C at 37°C | ±0.3°C at 37°C |
| Temperature Uniformity | ±0.5°C at 37°C | ±0.5°C at 37°C |
| Timer | 0–999 hr 59 min | 0–999 hr 59 min |
| CO2 Measurement | Infrared (IR) sensor | Infrared (IR) sensor |
| CO2 Control Range | 0–20% | 0–20% |
| CO2 Accuracy / Increment | ±0.3% / 0.1% | ±0.3% / 0.1% |
| CO2 Stability | ±0.1% | ±0.1% |
| O2 Measurement | — | Zirconia O2 sensor |
| O2 Control | — | Standard (1%–25%), optional hyperoxia |
| O2 Accuracy | — | ±0.2% |
| N2 Control | — | Auto-regulated for O₂ balance |
| Humidity | ~95% RH at 37°C | ~95% RH at 37°C |
| HEPA Filtration | ISO Class 5 (5 min recovery) | ISO Class 5 (5 min recovery) |
| Temperature Recovery | ≤10 min | ≤10 min |
| Gas Recovery (CO2) | ≤5 min | ≤5 min |
| Gas Ports | CO2 inlet | CO2, O2, N2 ports (configurable) |
