IG-96M PROBE SONICATOR:
The IG-96M Probe Sonicator is an advanced scientific instrument designed for precise control and high performance PID microprocessor for enhanced accuracy and a 5-inch TFT touchscreen, it allows intuitive operation of ultrasonic power, time, and gap adjustments with accuracy down to 0.1 seconds. This model combines cutting edge technology with user-friendly design, empowering researchers with detailed control over their experiments and a comprehensive display of essential parameters.
FEATURES:
Large Display & Intuitive Interface: Equipped with a 5-inch TFT touchscreen and PID microprocessor for accurate control.
Ultrasonic Power Control: Power can be set in 1% increments, offering precise adjustments from 1 – 99%.
Comprehensive Display Functions: Displays sample temperature, frequency, computerized tracking, and automatic trouble warnings on a large LCD screen.
Flexible Operation Modes: Includes pulse, continuous, and rest functions to suit various experimental needs.
Accurate Timing Controls: Ultrasonic time, gap time, and total time can be set to 0.1-second precision.
Advanced Safety Features: Features temperature alarms adjustable from 0.1 to 99°C to prevent sample overheating and alarms for time, temperature, and overload.
SPECIFICATIONS:
| Model | IG-96M |
| Frequency | 20-25 KHz, Automatic tracking |
| Display | LCD |
| Power | 650W |
| Power Range | 1-99% |
| Display function | Temperature, Power, Time etc |
| Timer (Selectable) | Yes |
| Overload Protection | Yes |
| User password Protection | Available |
| Input method | Touch Screen control |
| Std.Tip (Φ) | 6 mm (1/4”) |
| Tip options(Φ) | 3,6,8,10 mm |
| Processing Volume | 0.5-500 ml |
| Duty Ratio | 0.1-99.9% |
| Duty Ratio | 0.1-99.9% |
| Date memory | 20 groups |
| Temperature Alarm | 0.1-99°C (Prevent sample overheating) |
| Alarm | Time, temperature, overload |
| Power Supply | 220V 50Hz/60Hz |
| Dimensions (LxWxH) (mm) | 490x370x280 |
| Weight | 10kg + 5kg (Sound Proof Enclosure) |
